Specs
Overview
- 597cc EFI Engine
- Relocated Radiator & Snorkels
- 28" x 9" Maxxis Zilla Mud Tires
- 3,500 lb. WARN Winch w/Synthetic Rope
Engine & Drivetrain
| Alterra 600 HO Mud Pro | Alterra 600 HO Mud Pro | |
|---|---|---|
Engine Type | Liquid-Cooled, Single Cylinder | Liquid-Cooled, Single Cylinder |
Displacement <!--> | 597cc | 597cc |
Drive Train --> | CVT - CVTech Trailbloc | CVT - CVTech Trailbloc |
Drive System <!--> | 2WD/4WD Electric Actuation w/Selectable Front Diff Lock/Lower gear Ratio Transaxle | 2WD/4WD Electric Actuation w/Selectable Front Diff Lock/Lower gear Ratio Transaxle |
Fuel System --> | Electronic Fuel Injection (EFI) | Electronic Fuel Injection (EFI) |
Gear Selection <!--> | H/L/N/R/P | H/L/N/R/P |
Front Differential --> | 2WD / 4WD Electric Actuation w/Diff Lock | 2WD / 4WD Electric Actuation w/Diff Lock |
Rear Differential <!--> | Locked | Locked |
Steering & Suspension
| Alterra 600 HO Mud Pro | Alterra 600 HO Mud Pro | |
|---|---|---|
Steering --> | Electronic Power Steering | Electronic Power Steering |
Front Suspension <!--> | Arched Double A-Arm, High Clearance with 8.75 in. (22.2 cm) Travel | Arched Double A-Arm, High Clearance with 8.75 in. (22.2 cm) Travel |
Rear Suspension --> | Arched Double A-Arm, High Clearance with 8.75 in. (22.2 cm) Travel | Arched Double A-Arm, High Clearance with 8.75 in. (22.2 cm) Travel |
Brake System <!--> | Dual Front Hydraulic Disc, Single Rear Hydraulic Disc | Dual Front Hydraulic Disc, Single Rear Hydraulic Disc |
Foot Brake --> | Foot Operated Rear Brake | Foot Operated Rear Brake |
Parking Brake <!--> | Park in Transmission | Park in Transmission |
Front Tires --> | Maxxis Zillas 28 x 9-14 | Maxxis Zillas 28 x 9-14 |
Rear Tires <!--> | Maxxis Zillas 28 x 9-14 | Maxxis Zillas 28 x 9-14 |
Wheels --> | 14-in. Aluminum | 14-in. Aluminum |
Performance
| Alterra 600 HO Mud Pro | Alterra 600 HO Mud Pro | |
|---|---|---|
Total Capacity <!--> | 415 lb (188.2 kg) | 415 lb (188.2 kg) |
Front Rack --> | N/A | N/A |
Rear Rack <!--> | 200 lb (90.7 kg) | 200 lb (90.7 kg) |
Towing Capacity --> | 1,050 lb (476 kg) | 1,050 lb (476 kg) |
Dimensions
| Alterra 600 HO Mud Pro | Alterra 600 HO Mud Pro | |
|---|---|---|
Overall Length <!--> | 88.3 in (224.2 cm) | 88.3 in (224.2 cm) |
Overall Width --> | 46.5 in (118.1 cm) | 46.5 in (118.1 cm) |
Overall Height <!--> | 51.1 in (129.7 cm) | 51.1 in (129.7 cm) |
Overall Weight --> | 892 lbs. (404.6 kg) | 892 lbs. (404.6 kg) |
Wheel Base <!--> | 52 in (132 cm) | 52 in (132 cm) |
Ground Clearance --> | 12.8 in (32.5 cm) | 12.8 in (32.5 cm) |
Fuel Capacity <!--> | 4.8 gal (18.2 L) | 4.8 gal (18.2 L) |
Hitch --> | Standard 2-in Receiver | Standard 2-in Receiver |
Color Options
| Alterra 600 HO Mud Pro | Alterra 600 HO Mud Pro | |
|---|---|---|
Standard Colors <!--> | Black Magic | Black Magic |
Features
| Alterra 600 HO Mud Pro | Alterra 600 HO Mud Pro | |
|---|---|---|
Skid Plate --> | Full Length | Full Length |
Standard Instrumentation <!--> | Multifunctional Digital Gauge | Multifunctional Digital Gauge |
Lighting --> | Dual High/Low Beam Halogen Headlights with LED Accents, Single LED Brake Light/Tail Light | Dual High/Low Beam Halogen Headlights with LED Accents, Single LED Brake Light/Tail Light |
Start Method <!--> | Electric Start | Electric Start |
Standard Accessories --> | Composite Rear Rack, Front and Rear Bumper, Front Tow Hooks, Operator Accessible Storage, Color Matched Cut and Sewn Seat, Raised Steel Footpegs, 3,500-lb. WARN Winch w/Synthetic Rope | Composite Rear Rack, Front and Rear Bumper, Front Tow Hooks, Operator Accessible Storage, Color Matched Cut and Sewn Seat, Raised Steel Footpegs, 3,500-lb. WARN Winch w/Synthetic Rope |
